“Axalta Irus Mix has quickly become an essential part of our daily work. It really is a great support in the color mixing process. It is easy to use, fast and precise. It is also flexible, so I can mix small quantities as well as large. One of the things I appreciate most is that I can do other work while the paint is being mixed by Axalta Irus Mix. I would wholeheartedly recommend Axalta Irus Mix to other bodyshops. It is the future of our industry.”
Irus Mix Features
- Fully automatic dispenser for Automotive Refinish
- Original bottles of Axalta brands Standox, Spies Hecker and Cromax
- Machine dimension:
H: 231 cm (240 cm needed)
D: 72
L: 237 cm (+ access on right side)
- Total max. 120 pump positions (16 x 1,5L positions and 104 x 0.8L/0.35L/0.1L positions)
- Color indication on status of Irus Mix
yellow = working, red = faulty, green = ready - Non explosion proof: Non-Atex
PUMP UNITS – accurate and durable
- Auto pick & placing of pump units
- Pump units with punch tool for vented bottles
- Unique positioning of pump units in Irus Mix
- Piston pumps for high speed dosing
- 3-way valve; simple durable, reproducable
- Warning levels to indicate replacing bottle
ROBOT ARM – high-speed placement
- Robot picks and shakes pump unit, moves left/right and up/down along rails,
- Delivers pump unit to dispensing position
- Picks up the next pump unit while dispensing
- Robot delivers pump unit to its correct position after dispensing
- High speed placement
- Daily maintenance (2 x) of each pump unit to secure stability of the tints (no interruption of work)
DISPENSING – fully autonomous
and extremely precise
- Fully controlled dispensing by 50ml piston pumps
- Direct interfacing with scale
- Starts always with biggest component
- Minimum shot size 0.05gr
- Automatic nozzle cleaning after dispensing
SCALE – highly accurate and user-friendly
- Operator friendly
- Automatic can table (space to put scale and cup)
- Including scale up to 7,5 kgs for accurate results, minimum accuracy 0.05gr
- Display for visual check
- Laser positioning
- Full visibility on dispensing process
- Direct communication with software
- Software driven instructions for placing mixing cups
- Scale to go down to exit position when ready
Ebubekir Kurt
Refinisher, Jülicher Lack- und Karrosseriecenter GmbH.
Jülich, Germany
Testimonial
